Zebra LS12031 Barcode Scanner

Viet Pos specializes in distributing and installing various types of Zebra LS12031 barcode readers nationwide. The product has a competitive price, but the quality it brings will satisfy you. Please contact us immediately via hotline: 0905 295 337 for quick consultation and quotation.

I. Description of Zebra LS12031 Barcode Reader

The Symbol LS1203-HD barcode reader is designed for electronics manufacturers who need to scan small, high-density 1D barcodes on PCB component assemblies for tracking, traceability, quality assurance, and other applications. The scanner provides the functions, features, and reliability needed to increase operational efficiency from the start. Its single-board construction and durable scanning element significantly reduce downtime and repair costs, and multiple interfaces help ensure connectivity to your system now and in the future.

II. Features

1. Durable, single-board construction Withstands 5 ft drop tests, significantly reducing downtime and repair costs. 2. Multiple interfaces: RS232, USB, keyboard wedge (KBW) in one scanner Simplifies installation and integration, ensuring future compatibility. 3. Sleek, lightweight, and convenient design Maximizes comfort for all-day use. 4. Intuitive scanning and plug-and-play capability Minimizes setup and training time. 5. Choice of trigger or continuous mode Ensures flexible, accurate scanning from the start.

III. Technical Specifications

Zebra LS1203 Barcode Reader
Wired	Yes
Dimensions	2.4 in H x 7.1 in D x 2.4 in W (6.2 cm H x 18 cm D x 6 cm W)
Voltage and Current	5 +/-10%VDC @ 100 mA (Standby:
Color	Twilight Black
Weight	Approximately 4.3 oz. / 122 g (without cable)
Handheld	Yes
Power Source	Host power or external power supply; depending on host type
Wired	Yes
OPERATIONAL CHARACTERISTICS
Supported Interfaces	Keyboard Wedge, RS-232, USB
Skew (Yaw)	± 60°
Roll (Tilt)	± 30° from normal
Depth of Field	From contact to 8 in./20.32 cm on 100% UPC/EAN symbols
Scan Pattern	Single line
Decode Capability	1D, See data sheet for full list of supported symbologies
Pitch	± 65°
Minimum Resolution	30% minimum reflectance
Technology	Laser
REGULATORY SPECIFICATIONS
Electrical Safety	UL 60950-1, C22.2 No. 60950-1, EN 60950-1, IEC 60950-1
Laser Safety	EN 60825-1, IEC 60825-1, 21CFR1040.10
EMC	FCC Part 15 Class B, ICES 003 Class B
Environmental	RoHS Directive 2002/95/EEC
WARRANTY
Scanner Warranty	1 year from date of shipment. Liquid Polymer Scan Component includes a limited lifetime warranty. See full warranty for details.
USER ENVIRONMENT
Drop Specification	Withstands multiple 5 ft./1.524m drops to concrete
Ambient Light Immunity	Unaffected by direct exposure to normal office and factory lighting conditions, as well as direct sunlight
Storage Temperature	-40° to 158° F/-40° to 70° C
Operating Temperature	32° to 122° F/0° to 50° C
