CAT 5e UTP Indoor Network Cable - XL500-C-L

Indoor CAT 5e UTP Network Cable - XL500-C-L | Stable, efficient network connection solution for internal systems

In the digital age, ensuring stable and high-speed internal network connectivity is a prerequisite for improving work performance, especially in offices, surveillance camera systems, smart homes, and small data centers. With a design specifically for indoor environments, the CAT 5e UTP XL500-C-L network cable is a reliable choice for all projects requiring consistent performance and durability over time.

1. 4 twisted pairs design – Reduces interference, increases performance

The XL500-C-L cable belongs to the UTP (Unshielded Twisted Pair) category – twisted pair cable without a shield. However, the product is manufactured with 4 tightly twisted pairs to minimize crosstalk and electromagnetic interference from nearby devices. Each pair of wires is clearly color-coded:

• Blue / white – blue

• Orange / white – orange

• Green / white – green

• Brown / white – brown

This design facilitates quick, convenient installation and ensures accuracy when crimping RJ45 connectors.

2. Premium materials – Ensures high performance and longevity

The XL500-C-L cable uses a copper-clad aluminum (CCA) core with a diameter of 0.5 mm ± 0.015 mm, meeting the 24 AWG wire standard – both cost-effective and ensuring stable signal transmission over standard distances. The high-quality HDPE insulation (High-Density Polyethylene) has a uniform and precise thickness, helping to prevent signal loss, resist moisture, and withstand heat well.

The flexible, abrasion-resistant PVC outer sheath, with an overall diameter of 5.05 mm ± 0.2 mm, is suitable for installation in cable trays, conduits, or exposed indoor wiring without worrying about bending or damage over time.

3. Powerful Transmission Performance – Suitable for Many Applications

The XL500-C-L network cable is designed to operate stably at frequencies up to 100 MHz, meeting the demands of 100Mbps Ethernet applications and compatible with network standards such as:

• Fast Ethernet (100BASE-TX)

• IP camera applications

• Computer – modem – switch connections

• Smart home systems

Notable transmission parameters include:

• Conductor resistance ≤ 9.38Ω / 100m – ensures low signal loss

• Insulation resistance ≥ 5000 mega ohm-km

• Delay skew ≤ 45ns – ensures uniform signal transmission

• High dielectric strength – No breakdown at 1000VDC for 1 minute

• Impedance: 100Ω ± 20Ω – meets CAT 5e technical standards

4. Durable Operation in Harsh Conditions

Although it is an indoor network cable, the XL500-C-L still demonstrates superior durability with the ability to operate in temperatures from -20°C to +60°C, ensuring stable signals even if the system is placed near heat-generating equipment or in areas with fluctuating climates.

The inner nylon cushioning layer increases elasticity and prevents breakage during installation and long-term use.

5. Flexible Practical Applications

Thanks to its sturdy structure, standard materials, and stable transmission capabilities, CAT 5e UTP XL500-C-L Cable is an ideal solution for:

• Internal LAN systems in offices, schools, hospitals

• Connecting surveillance cameras for security systems

• Internal networks in apartments, smart homes

• Network cabinets, switches, modems in mini server rooms

Especially, with its competitive price and ease of installation, the XL500-C-L cable is favored by network system installers, camera installers, and businesses needing to expand their internal transmission infrastructure.

Conclusion

CAT 5e UTP XL500-C-L network cable is not only an economical choice but also provides stability and peace of mind during use. With quality materials, optimal design, and superior transmission capabilities, this is an ideal product for deploying internal network systems of all sizes.
