Chainway CM2000-1 UHF RFID Module (1-Port) - Impinj Indy R2000

· Còn hàng Bảo hành 12 tháng

Category: Đầu đọc RFID cố định (Fixed Mount Reader)

Contact for quote

Liên hệ để nhận báo giá nhanh trong 30 phút

Chainway CM2000-1 is a single port UHF RFID reader module. The module uses the Impinj R2000 chip, delivering a read range over 10m. It can be integrated into mobile UHF RFID readers, fixed readers, card readers, and integrated RFID readers. With a high level of integration, the module is small in size, low in power con…

Giao hàng toàn quốc

Hỗ trợ kỹ thuật 24/7

Chính hãng 100%

4 văn phòng HCM·ĐN·CT·HN

Description

Chainway CM2000-1 is a 1-port (single port) UHF RFID reader module, using the Impinj Indy R2000 chip, dimensions 57.2mm x 36.8mm x 7.6mm, weight 26.0g / 0.92oz, working frequency 865-868 / 920-925 / 902-928 MHz, output power 5-30 dBm adjustable, reading rate up to 900 tags/s, reading range up to 24m (with 4dBi antenna & M750 tag).

Chainway CM2000-1 UHF RFID Module (1-Port) - Impinj Indy R2000 - image 1

Key Features

Based on Impinj Indy R2000 chip
Exceptional Tag Reading Performance
Superior Stability
Excellent Heat Dissipation
Low Power Design
Consistent Performance
Powerful UHF Read/Write
High integration level, small in size, low in power consumption, resistant to electromagnetic interference and good at heat dispersion
Can be integrated in mobile UHF RFID readers, fixed readers, card readers, integrated RFID readers, etc.
