DH9809USB-L - UHF RFID Desktop Reader/Writer 920-925MHz, USB, ISO18000-6C/6B, SDK

DH9809USB-L is a high-performance desktop UHF RFID reader supporting ISO18000-6C (EPC C1G2) and ISO18000-6B tags, frequency range 860~868MHz / 902~928MHz, adjustable RF output power up to 13dbm, built-in antenna with effective distance up to 200mm, USB2.0 interface (VSP or HID), includes SDK and demo software.

Key Features

• Self-intellectual property
• Supports tags compliant with ISO18000-6C (EPC C1G2) and ISO18000-6B standards
• Frequency range 860~868MHz, 902~928MHz (frequency customization optional)
• FHSS or Fix Frequency transmission
• RF output power up to 13dbm (adjustable)
• No external power source needed
• Built-in antenna, effective distance up to 200mm*
• Supports USB2.0 interface with VSP (Virtual Serial Port) or HID mode
• Slim outline
• Provides SDK and demo software for further development

* Effective distance depends on protocol, tag, and environment.

Recommended Applications

• Logistics
• Access control
• Time attendance
• Anti-counterfeiting
• Industrial production process control

Contact 0935 498 384 for a quote.
