Expansion Control Panel - DM10

SKU: DM10 · Còn hàng Bảo hành 12 tháng

Category: Smart Access Control, Door Control, Accessories

Contact for quote

Liên hệ để nhận báo giá nhanh trong 30 phút

DM10 – RS485 Door Lock Expansion Board DM10 is a dedicated auxiliary control board in access control systems, designed to work in conjunction with main control devices such as F18, Horus, C2-260, and other devices that support RS485 communication. This expansion board does not store user data, but instead controls lo…

Giao hàng toàn quốc

Hỗ trợ kỹ thuật 24/7

Chính hãng 100%

4 văn phòng HCM·ĐN·CT·HN

Description

DM10 – RS485 Door Lock Expansion Board

DM10 is a dedicated auxiliary control board in access control systems, designed to work in conjunction with main control devices such as F18, Horus, C2-260, and other devices that support RS485 communication. This expansion board does not store user data, but instead controls locks, processes signals from readers and Exit buttons, optimizing stable operation and security.

Outstanding Features

RS485 Communication: Compatible with A&C devices supporting RS485, ensuring stable data transmission over long distances.
Lock Control Only: Does not store user data, enhancing system security.
Dual Wiegand Reader Support: Connects 2 access control card readers.
Full I/O Signal Integration: Includes door sensor, Exit button, auxiliary AUX IN/OUT.
Convenient Power Supply: Supports DC 12V input and output, easy to integrate into existing systems.

Bảng Điều Khiển Mở Rộng Khóa Cửa Qua RS485

Technical Specifications

Technical Specifications	Details
Model	DM10
Main Communication Port	RS485
Supported Readers	2 Wiegand readers
Power Input/Output	DC 12V
Input Signal	1 door sensor, 1 Exit button, 1 AUX IN
Output Signal	1 AUX OUT
Data Storage Function	None – depends on the control device
Compatible Devices	F18, Horus Series, C2-260 and RS485 models
