Swing Barrier - SBTL5200

SKU: SBTL5200 · Còn hàng Bảo hành 12 tháng

Category: Control - Timekeeping, Smart Access Control, Lane Security Gate, Swing Barrier Gate

Contact for quote

Liên hệ để nhận báo giá nhanh trong 30 phút

SBTL5200 Turnstile – Effective, Durable Security Control Solution SBTL5200 Turnstile is a security turnstile designed for smooth , stable , and energy-efficient operation, providing an effective access control solution for buildings, offices, factories, and commercial centers. With its luxurious stainless steel design…

Giao hàng toàn quốc

Hỗ trợ kỹ thuật 24/7

Chính hãng 100%

4 văn phòng HCM·ĐN·CT·HN

Description

SBTL5200 Turnstile – Effective, Durable Security Control Solution

SBTL5200 Turnstile is a security turnstile designed for smooth, stable, and energy-efficient operation, providing an effective access control solution for buildings, offices, factories, and commercial centers. With its luxurious stainless steel design and ability to integrate various modern authentication methods, the SBTL5200 is an optimal choice for any access control system.

Outstanding Advantages

SUS304 stainless steel material: Ensures high durability, corrosion resistance, suitable for both indoor and semi-outdoor environments.
Smooth and quiet operation: Suitable for environments requiring seriousness and low noise such as offices, hospitals, banks.
Low power consumption, helping to save long-term operating costs.
Emergency mode support: Automatically opens during power outages or fire alarms, ensuring safe evacuation for users.
Flexible integration: Can be integrated with RFID readers, fingerprints, QR codes, or facial recognition.

Technical Specifications

Parameter	Value
Power supply	AC 100–120V / 200–240V, 50/60Hz
Operating temperature	-28°C to 60°C
Operating Humidity	20% to 95% RH (non-condensing)
Throughput Rate	RFID: ≤30 people/min – Fingerprint: ≤25 people/min
Passage Width	650mm (customizable up to 850mm)
Footprint Dimensions	1400 × 780 mm
Product Dimensions	1400 × 180 × 1000 mm
Packaging Dimensions	1500 × 260 × 1100 mm
Net Weight	72 kg
Packaged Weight	87 kg
Cabinet Material	SUS304 Stainless Steel
Lid Material	Tempered Glass
Barrier Material	Tempered Glass (optional: acrylic)
Operating Mechanism	Rotary
Security Level	Medium
Emergency Mode	Supported
Warranty	12 months
