VP-E262 Active RFID Tag

Active RFID Tag VP-E262 is a crucial component in an active RFID system. The Active RFID Tag VP-E262 acts as a locator in the system; it sends LF signals to activate standby active tags in its area, then the active tag sends the same activation address and tag ID to the RFID reader. The E262 can activate other linked tags. With the help of an active RFID reader, LF Activator, and LF Wake Up Active Tag, this combination can achieve area positioning and detect movement direction. At the same time, the wake-up tag has a longer battery life.

Basic Specifications

Dimensions	189mm *90mm *40mm (L×W×H)
Weight	225g
Working Voltage	DC 12V (compatible with DC 9-18V)
Power Consumption	5W
Operating Temperature	-20°C ~+55°C
Storage Temperature	-40°C ~+80°C
Humidity	5%~95% (non-condensing)
Waterproof	IP64

RF Specifications

Operating Frequency	125KHz ±1KHz
Tag Activation Area	1-6m (Adjustable activation radius)
Modulation Type	Software adjustable (RS485) or hardware configurable
Antenna Output Power	<5W
Activation Code	8 bit
Working Indicator	LED light, buzzer
