White Wooden RFID Card 13.56MHz F08 Chip

White wooden RFID card 13.56MHz F08 chip is a contactless card using the FM11RF08 (F08) chip according to the ISO14443 Type A standard, dimensions 85.6*54mm, frequency 13.56MHz, EEPROM 1K × 8bits, maximum read distance ~100mm, data transfer rate 106 kbit/s.

Key Features

• Three-step mutual authentication (ISO/IEC DIS 9798-2)
• Contactless data transmission and power supply (no battery required)
• Operating distance: up to 100mm (depending on antenna shape)
• Operating frequency: 13.56 MHz
• Data transfer: 106 kbit/s
• Anticollision
• Typical ticketing transaction: < 100 ms (including backup management)

Suitable Applications

• Payment
• Access control
• Time attendance
• Hotel key cards
• Public transport
• Event ticketing

Contact 0935 498 384 for a quote.
