Custom Woven RFID Wristband ISO 14443A for Festivals & Concerts

The custom ISO 14443A woven RFID wristband for festivals and concerts is an RFID wristband using the MIFARE Ultralight C chip (MF0ICU2), operating frequency 13.56 MHz, ISO/IEC 14443 Type A standard, operating distance up to 100 mm, data transfer rate 106 kbit/s, 1536-bit EEPROM. Material: woven + mini PVC or PVC + epoxy, tag size 39x23mm with a 2x18mm hole, custom woven strap length typically 400mm.

Key Features

• MIFARE RF Interface (ISO/IEC 14443 A): contactless data transmission and power supply
• Operating distance up to 100 mm depending on antenna geometry and reader configuration
• Operating frequency 13.56 MHz
• Data transfer 106 kbit/s
• Data integrity 16-bit CRC, parity, bit coding, bit counting
• True anticollision, 7-byte serial number (cascade level 2 per ISO/IEC 14443-3)
• Typical ticketing transaction: < 35 ms; fast counter transaction: < 10 ms
• Total EEPROM 1536-bit; 512-bit MF0ICU1 compatible; 36 pages, 1152-bit user read/write area
• Field programmable read-only locking function per block; per page for the first 512-bit
• 16-bit one-way counter; 32-bit user-defined OTP area
• Write endurance 100,000 cycles; data retention 10 years
• Material: woven + mini PVC or PVC + epoxy
• Tag size: 39x23mm with a 2x18mm hole
• Custom woven strap length, typically 400mm
• Personalization: print LOGO or NUMBER; laser RUNNING NUMBER, UID NUMBER or LETTER

Recommended Applications

• Events
• Concerts
• Parks
• Event ticketing

Contact 0935 498 384 for a quote.
